Unique in the field of self-loading concrete mixers, this very compact, agile and economical machine guarantees a yield of 2.8 m³ of concrete in every batch and a daily productivity of up to 75 to 90 m³. The DBS 2800 mixers are used as an alternative to small and medium batching plants. However, they have an advantage of extreme mobility (accentuated by driving reversibility and the drum rotation system for 360° discharge), flexibility and autonomy. By equipping the DBS 2800 with the computerized CBV 2.0 production process, it is possible to obtain the production of certified high quality concrete. Constancy, repeatability and quality of the concrete batch are the unrivalled advantages of the CBV 2.0 technology, exclusive to the FIORI GROUP self-loading concrete mixers.
‣ Unparalleled agility and stability; even in loaded condition due to lower center of gravity
‣ Four-wheel drive & steering
‣ Reversible driving seat & 245° drum rotation
‣ High pressure automotive hydrostatic transmission for working on any kind of terrain
‣ CBV version – A computerized electronic batching system ensures accurate precise dosing
‣ Fully integrated and interactive system, guides the operator right from entering the mix design, precise dosing, controlling the mixing time and ensuring homegenity of the final product.
‣ Multiple recipes can be saved
‣ Humidity percentage can be input and the system automatically adjusts the water inflow thus maintaining the water cement ratio.
‣ Batch report printed for every batch of concrete produced
‣ Final check of the quality of concrete produced
‣ Improved homogenization, reduced mixing times and greater quality of concrete
‣ Special double truncated cone-shaped drum with convex bottom
‣ Dual-screw mixing system
‣ Pressure sensor installed on the drum pump assists in confirming the homogenity of the concrete in the drum before discharging
‣ Ergonomic controls – multifunction joystick to the left of the operator
‣ Level 1 ROPS FOPS cabin – (Level 2 available as option)
‣ Patented drum rotation feature combining the reversible driving allows full control over the mix directly from the cabin
‣ The 245° drum rotation, in fact, ensures complete visibility thus allowing the operator to check the consistency of the mix from the cabin
‣ Equipped with a standard ground control panel (always available to the operator) to manage, program and control water input into the drum, as well as the mixing/unloading functions
‣ Loading arm driven by Z-shaped auto-compensated kinematic mechanism with two lifting cylinders and two double acting loader cylinders
‣ Tip-off function to shed excess material before weighing and pouring in the drum
‣ Electro-Hydraulically operated hatch – prevents any losses by avoiding spilling of materials
Mahindra CEV Stage V Turbocharged Intercool, 4 Cylinder CRDI engine
Max Power : 55 kw (74.8 HP)
Battery : 12V-150Ah (640A)
Hydrostatic “automotive” transmission with variable displacement pump and variable displacement hydraulic motor with electro- hydraulic control, and reverse gear control on the steering wheel. There are 4 forward gears & 2 reverse gears
Max Speed : 25 km/h Max Gradient : 23 deg Tyre Size : 405/70-20 16PR
Internal oil-bath disc service and emergencybrakes acting on the 4 wheels, activation with mini servo pump on independent dual circuit. Negative type parking brake, with internal oil- bath discs onthe rear axle and release.electro- hydraulically controlled
Load-sensing power steering with double displacement on 4 steering wheels & steering selection device enables the machine to operate as a 2-Wheel Steering, 4-Wheel Steering & Crab Steering.
“Self-priming” water pump with quick- suction, Max Head : 4 bar
Two connected tanks positioned opposite each other made of polyethylene with a total capacity of 570 liters.
Water feeding to the drum controlled by means of electromagnetic flow meter. Water pump activation from the driver’s seat and from the ground panel. Suction selection from the ground with quick- coupling pipes.
Double-cone drum with double-spiral mixing screws and convex bottom.
Production Capacity is 2.8 cu.m. Class S1 concrete. Electronic drum rotation system : Constant Speed Drive. Drum rotation control from the cabin & from the ground panel.
Unloading chute with hydraulic tilting by means of a double-acting jack and 180 deg rotation. Drum swivel rotation up-to 245 deg & drum raising to horizontal position by means of two double-acting jacks.
Fiori Batch Controller CBV 2.0 is a proprietary system of Fiori Group for concrete production process management and control.
The unrivalled technology of the CBV 2.0 guarantees consistency and certifiability of the concrete produced and thereby ensuring a controlled, accurate, fast and documented process.
Fuel tank : 110 liters
Total hydraulic system capacity : 125 liters
Engine Oil : 13.5 liters
Gear pump
Max. flow rate : 45 liters/min. Maximum pressure : 180 bar
6-element distributor servo-controlled with multi- function joystick. Aluminum heat exchanger for hydraulic oil cooling.Pressurized closed-circuit intake with oil filter replaceable from the outside.
Loading arms with self-compensated kinematic mechanism, double-acting loader lifting & return cylinders, electro-hydraulically controlled hatch with standard Tip-Off function.
Volumetric capacity : 510 liters
Cabin Design in accordance with ROPS & FOPS Level – I standards. Anatomic seat with flexible suspension and height adjustment, seat belts.
LCD TV display with camera for rear visibility (optional)
Width : 2275 mm
Length : 5250 mm
Height : 3830 mm
Max Gross Weight : 12760 kg
UnladenWeight : 7660kg
