Economy and productivity are the distinctive elements of the DBX 5000. The DBX 5000 is the most economical and largest capacity concrete mixer with front loading ever made. Compact in size & highly agile, the DBX 5000 guarantees a maximum yield of 5.0 m³ of concrete in every batch. The unique positioning of the drum and the specially designed loading arm gives enhanced visibility during loading and casting operations. The DBX 5000 is equipped with an innovative clamshell bucket which maximizes loading efficiency and thereby minimise the batching time. This enables reaching a daily productivity of up to 120-130 m³ of concrete. By equipping the DBX 5000 with the exclusive computerized batch controller system CBV 2.0, it is possible to obtain the production of certified quality concrete everywhere.
‣ Low centre of gravity ensures unparalleled agility and stability
‣ 4 wheel drive and steering – All-terrain capability. Excellent off-road performance
‣ Hydrostatic transmissions enable easy movement
‣ Compact – Dramatically reduced dimensions allows the mixer to freely move in constrained locations
‣ Front Loading System
‣ Electro-hydraulically operated hatch – prevents loading losses → Zero spillage of materials
‣ Grab bucket – 680 liters ensures high productivity
‣ Digital electronic water meter – control water inflow into the drum directly from cabin
‣ Great accuracy in aggregate weighing
‣ CBV version – A computerized electronic batching system ensures accurate precise dosing
‣ Fully integrated and interactive system, guides the operator right from entering the mix design, precise dosing, controlling the mixing time and ensuring homegenity of the final product.
‣ Multiple recipes can be saved
‣ Humidity percentage can be input and the system automatically adjusts the water inflow thus maintaining the water cement ratio.
‣ Batch report printed for every batch of concrete produced
‣ Final check of the quality of concrete produced
‣ Improved homogenization, reduced mixing times and greater quality of concrete
‣ Special double truncated cone-shaped drum with convex bottom
‣ Dual-screw mixing system
‣ Dual Controls for Mixing & Unloading
- Can be controlled from Cabin
‣ Closed cabin installed to the right of the vehicle
‣ Ergonomic controls – multifunction joystick to the left of the operator
‣ Level 1 ROPS FOPS cabin – (Level 2 available as option)
‣ Wide cabin wind screen and the specially designed loading arms improves visibility
‣ Cabin – Glass on three sides – Great visibility during loading as well as during casting
‣ Drum fitted at the rear in a slightly turned position – Enhanced visibility
‣ Anatomic seat (with seat belt) equipped with flexible suspension and height adjustment. Provides maximum comfort during long working hours and ensures operator safety
Mahindra CEV Stage V Turbocharged Intercool, 4 Cylinder CRDI engine
Max Power : 83.5 kw (112 HP)
Battery : 12V-150Ah (640A)
Hydrostatic “automotive” transmission with variable displacement pump and variable displacement hydraulic motor with electro- hydraulic control, and reverse gear control on the steering wheel. There are 4 forward gears & 2 reverse gears
Max Speed : 28 km/h Max Gradient : 23 deg Tyre Size : 18-19.5 18PR
Internal oil-bath disc service and emergencybrakes acting on the 4 wheels, activation with mini servo pump on independent dual circuit. Negative type parking brake, with internal oil- bath discs on the front axle and electro- hydraulically controlled release.
Load-sensing power steering with double displacement on 4 steering wheels & steering selection device enables the machine to operate as a 2-Wheel Steering, 4-Wheel Steering & Crab Steering.
“Self-priming” water pump with quick- suction, Max Head : 4 bar
Two connected tanks positioned opposite each other made of polyethylene with a total capacity of 1200 liters.
Water feeding to the drum controlled by means of electromagnetic flow meter.
Water pump activation from the driver’s seat. Suction selection from the ground with quick- coupling pipes.
Double-cone drum with double-spiral mixing screws and convex bottom.
Production Capacity is 5 cu.m. class S1 concrete. Electronic drum rotation system : Constant Speed Drive. Drum rotation control from the cabin
Unloading chute with hydraulic tilting by means of a double-acting jack and control placed inside the cabin.
Fiori Batch Controller CBV 2.0 is a proprietary system of Fiori Group for concrete production process management and control.
The unrivalled technology of the CBV 2.0 guarantees consistency and certifiability of the concrete produced and thereby ensuring a controlled, accurate, fast and documented process.
Fuel tank : 90 liters
Total hydraulic system capacity : 125 liters
Engine Oil : 13.5 liters
Gear pump
Max. flow rate : 40 liters/min. Maximum pressure : 230 bar
4-element distributor servo-controlled with multi- function joystick. Aluminum heat exchanger for hydraulic oil cooling. Pressurized closed-circuit intake with oil filter replaceable from the outside.
Loading device with grab bucket and lifting arms controlled by double-acting hydraulic cylinders. Electro-hydraulically operated trap door.
Volumetric capacity : 680 liters
Cabin Design in accordance with ROPS & FOPS Level – I standards. Anatomic seats with flexible suspension ansd height adjustment seat belts.
LCD TV display with camera for rear visibility
Width : 2450 mm
Length : 5820 mm
Height : 3805 mm
Max gross Weight : 19280 kg
Unladen Weight : 7280 kg
